MAFELL MF 26 cc / 400 multi-cutter in transport case

The MAFELL MF 26 cc / 400 is a versatile professional multi-cutter designed for precise routing, sawing and slotting in a wide range of materials. Its robust construction combines a lightweight magnesium die-cast housing with impact-resistant glass-fibre-reinforced plastic components, providing durability for demanding workshop and construction applications.

The powerful 1400 W universal motor offers continuously variable speed from 3600 to 6250 rpm, allowing the machine to be adapted to different materials and applications. The routing depth can be adjusted from 0 to 26 mm, while the machine can also be used on the guide rail with a saw blade.

The M guide system is firmly connected to the MF 26 cc / 400, making the machine and guide rail a single working unit. With a maximum cutting length of 400 mm, it is particularly suitable for cross grooves, such as grooves in shelf boards and support boards. The guide system includes adjustable stops on the underside, allowing the angle to be set according to the scale. After the cut, a spring mechanism automatically returns the machine to its starting position.

The additional adjustment screw and scale allow the routing depth to be set with 0.1 mm precision. The depth indicator can be adjusted for use with or without the guide rail, so the exact selected depth remains clearly visible in both configurations.

The MF 26 cc / 400 is suitable for longitudinal and cross grooves, V-grooves, plasterboard folding and bending work, and aluminium composite panel processing. The supplied MF-VN 25 adjustable groove cutter allows variable groove widths from 15.4 to 25 mm, making it useful for routing channels in soft fibreboard, including channels for service lines.

The quick-opening protective hood provides convenient access. Opening the hood automatically activates the switch lock and saw-blade lock, increasing safety during tool changes and setup. The machine is supplied in a transport case for organised storage and transport.

Technical data

• Routing depth: 0–26 mm
• No-load speed: 3600–6250 rpm
• Rated input: 1400 W
• Motor: universal motor, 230 V / 50 Hz
• Weight: 6.3 kg

Delivery contents

• 1 × TCT saw blade 120 × 1.2/1.8 × 20 mm, Z 24, WZ, for universal use in wood – article 092558
• 1 × MF-VN 25 adjustable groove cutter – article 206074
• 1 × parallel guide
• 1 × M guide system, maximum cutting length 400 mm – article 208170
• 1 × 4 m connection cable – article 087323
• 1 × transport case
