Chain saw on a bar KSS 60 cc with carrying bag

Product Description

MAFELL's new powerful cross-cutting systems make a significant impact with their light weight and cutting depth of up to 60 mm, particularly in interior applications. Once the cut is made, the saw automatically returns to its starting position. The maximum cutting length, using the full cutting depth, is 408 mm (16 1/16 inches). Great power and high torque take on a whole new meaning with the newly developed high-performance CUprex motor. The saw comes with performance-optimized digital electronics and newly developed control technology. The saw speed continuously varies depending on the material properties and application. There is no longer a need to loosen the blade guard – FLIPPKEIL offers optimal user-friendliness and safety when cutting recesses.

Application Area

• Cuts with a guide rail
• Ripping and cross cuts
• Cutting recesses and grooves
• Suitable materials include solid wood, panel materials, insulation materials, doors, work surfaces, and interior finishing and renovation materials

Technical Specifications

• Cutting depth at 0° bevel: 0 – 61 mm
• Cutting depth at 45° bevel: 0 – 47 mm
• Cutting depth at 0° without bevel: 0 – 67 mm
• Cutting depth at 45° without bevel: 0 – 53 mm
• Bevel range: 0 – 45°
• Cutting length with bevel: 408 mm
• Cutting angle: – 60° – + 60°
• Nominal idle speed: 2700 – 4700 rpm
• Power: 1800 W
• Weight with bevel: 6.1 kg
• Motor: 230 V / 50 Hz

Included in the Package

• TCT saw blade 185 x 1.4/2.4 x 20 mm, Z 32, AT, clean cut, wood (092489)
• Parallel guide
• Bevel rail with cutting length of 400 mm (208170)
• Saw key 5 mm (093034)
• Electric cable 4 m (087323)
• Transport box
