Chainsaw on a beam KSS 60 cc

Product Description

MAFELL's new powerful cross-cut systems have a significant impact with their lightweight design and a cutting depth of up to 60 mm, making them ideal for interior work. Once the cut is made, the saw automatically returns to its starting position. The maximum cutting length, utilizing the full cutting depth, is 408 mm (16 1/16 inches). High power and torque take on a new meaning with the newly designed high-performance CUprex motor. The saw comes with performance-optimized digital electronics and newly developed control technology. The speed of the saw continuously adjusts depending on the properties of the material and its application. The blade guard no longer needs to be unscrewed – FLIPPKEIL provides optimal user-friendliness and safety when cutting recesses.

Application Areas

• Cross cuts with guide rail
• Longitudinal and cross cuts
• Cuts for recesses and grooves
• Suitable materials include solid wood, panel materials, insulation materials, doors, worktops, as well as interior finishing and renovation materials

Technical Specifications

• Cutting depth at 0° bevel: 0 – 61 mm
• Cutting depth at 45° bevel: 0 – 47 mm
• Cutting depth at 0° without bevel: 0 – 67 mm
• Cutting depth at 45° without bevel: 0 – 53 mm
• Bevel range: 0 – 45°
• Cutting length with bevel: 408 mm
• Cutting angle: – 60° – + 60°
• Nominal idle speed: 2700 – 4700 rpm
• Power: 1800 W
• Weight with bevel: 6.1 kg
• Motor: 230 V / 50 Hz

Included in the Package

• TCT saw blade 185 x 1.4/2.4 x 20 mm, Z 32, AT, clean cut, wood (092489)
• Parallel guide
• Bevel guide with a cutting length of 400 mm (208170)
• Saw key 5 mm (093034)
• Electrical cable 4 m (087323)
