Chainsaw on a rail KSS 50 cc with a carrying bag

Product Description

With its lightweight design and a cutting depth of up to 52 mm (2 1/16 inches), MAFELL's new powerful cross-cutting systems have a significant impact, for example, on interior work. Once the cut is made, the saw automatically returns to its starting position. The maximum cutting length, using the full cutting depth, is 407 mm (16 inches). There is no need to loosen the blade guard anymore – FLIPPKEIL provides optimal user-friendliness and safety during plunge cutting.

Application Area

• Cross cuts with guide rail
• Rip cuts and cross cuts
• Plunge cuts and grooves
• Suitable materials include solid wood, panel materials, insulation materials, doors, work surfaces, as well as interior finishing and renovation materials

Technical Specifications

• Cutting depth at 0° angle guide: 0 – 52 mm
• Cutting depth at 45° angle guide: 0 – 42 mm
• Cutting depth at 0° without angle guide: 0 – 58 mm
• Cutting depth at 45° without angle guide: 0 – 48 mm
• Angle range: 0 – 45°
• Cutting length with angle guide: 407 mm
• Cutting angle: – 60° – + 60°
• Nominal no-load speed: 5700 rpm
• Power: 1300 W
• Vacuum connection: 35 mm
• Weight with angle guide: 5.4 kg
• Motor: 230 V / 50 Hz

Included in the Package

• TCT saw blade 168 x 1.2/1.8 x 20 mm, Z 32, AT, clean cut, wood (092480)
• Angle guide, max. cutting length 400 mm (208170)
• Hex key 5 mm (093034)
• Electrical cable 4 m (087323)
• Transport case
