Chain saw on a rack KSS 50 cc

Product Description

With its lightweight design and cutting depth of up to 52 mm (2 1/16 inches), MAFELL's new powerful cross-cutting systems have a significant impact on interior work, for example. Once the cut is made, the saw automatically returns to its starting position. The maximum cutting length, using the full cutting depth, is 407 mm. There is no need to loosen the blade guard anymore – the FLIPPKEIL offers optimal user-friendliness and safety during plunge cutting.

Applications

• Cross cuts with guide rail
• Lengthwise and cross cuts
• Plunge and groove cuts
• Suitable materials include solid wood, panel materials, insulation materials, doors, worktops, and interior finishing and renovation materials

Technical Specifications

• Cutting depth at 0° with guide rail: 0 – 52 mm
• Cutting depth at 45° with guide rail: 0 – 42 mm
• Cutting depth at 0° without guide rail: 0 – 58 mm
• Cutting depth at 45° without guide rail: 0 – 48 mm
• Angle range: 0 – 45°
• Cutting length with guide rail: 407 mm
• Cutting angle: – 60° – + 60°
• Nominal no-load speed: 5700 1/min
• Power: 1300 W
• Vacuum connection: 35 mm
• Weight with guide rail: 5.4 kg
• Motor: 230 V / 50 Hz

Included in the Package

• TCT saw blade 168 x 1.2/1.8 x 20 mm, Z 32, AT, clean cut, wood (092480)
• Guide rail, max. cutting length 400 mm (208170)
• Hex key 5 mm (093034)
• Power cable 4 m (087323)
