MAFELL A 18 PURE cordless drill/driver in T-MAX

The MAFELL A 18 PURE is a professional 18 V cordless drill/driver designed for demanding drilling and screwdriving work on construction sites and in workshop environments. Its robust construction combines high torque with a compact format, making it suitable for a wide range of everyday professional applications.

The drill/driver delivers 65 Nm soft torque and up to 130 Nm hard torque. Two speed ranges provide controlled operation from 0–560 rpm in first gear and 0–1960 rpm in second gear. With a maximum drilling capacity of 68 mm in wood, the A 18 PURE is well suited to demanding timber construction and installation work.

The impulse function provides additional support in difficult situations, such as loosening seized screws or starting holes on smooth surfaces. The spindle features a 1/4-inch holder for direct bit use and quick-change accessories, while the supplied quick-change chuck provides a clamping range of up to 13 mm.

Safety and handling are enhanced by the electronic Anti-Kickback function, which actively switches off the motor in the event of a sudden rotational movement. Two integrated spirit levels help control the 90° angle during horizontal and vertical drilling or screwdriving.

The bright LED work lights with afterglow illuminate the working area over a broad, shadow-reduced field. Four magnetic bit holders positioned on both sides of the battery mount keep frequently used bits readily accessible.

The 43 mm clamping neck allows the A 18 PURE to be mounted in all MAFELL BST drilling stations. The machine is part of the Cordless Alliance System (CAS), providing compatibility with the corresponding CAS machines, battery packs and chargers.

The PURE version is supplied without a battery and charger, making it a practical choice for users who already have compatible 18 V MAFELL/CAS battery equipment. The complete set is supplied in a T-MAX transport and storage case.

Technical data

• Article number: 91C802
• Clamping neck diameter: 43 mm
• Chuck capacity: 13 mm
• Max. drilling diameter in wood: 68 mm
• Max. drilling diameter in steel: 13 mm
• Soft torque: 65 Nm
• Hard torque: 130 Nm
• Impulse torque, soft: 65 Nm
• No-load speed, 1st gear: 0–560 rpm
• No-load speed, 2nd gear: 0–1960 rpm
• Nominal voltage: 18 V
• Torque settings: 10 + 1
• Dimensions (L × W × H): 145 × 79 × 201 mm
• Vibration: <2.5 m/s²
• Sound pressure level: 79 dB(A)
• Sound power level: 88 dB(A)
• Weight: 1.2 kg

Delivery contents

• 1 × quick-change chuck A-SBF 13, article 206772
• 1 × quick-change bit holder A-SBH, article 206766
• 1 × belt clip
• 1 × auxiliary handle
• 1 × T-MAX transport and storage case

```
