Features

• More efficient and longer life brushless motor.

• Turbo mode for faster and more powerful drilling, up to 27% higher rotational speed.

• Highest torque of 158 Nm for drilling and screwdriving even in extreme conditions.

• Anti-kickback feature, shuts off the motor in case of jamming to prevent wrist twisting.

• Electronic management system (EMS) protects the machine, extends its service life and increases efficiency.

• Electronic quick brake.

• Durable gearbox housing made of die-cast aluminum.

• Metal chuck with push ring and automatic locking function.

• Right/left rotation with safety lock.

• Extendable handle offers user protection even at maximum torque.

• Ergonomically designed, non-slip and soft rubber handle.

• Integrated LED light.

• LED battery capacity indicator.

• FLEX battery system: compatible with all FLEX 18 V battery packs.

Technical specifications

• Battery voltage: 18 V

• Battery capacity: 2.5 / 5.0 / 8.0 Ah (depending on the set)

• No-load speed, 1st gear: 0 - 700 rpm

• No-load speed, 2nd gear: 0 - 2500 rpm

• Maximum torque, hard: 158 Nm

• Maximum torque, soft: 70 Nm

• Maximum drilling diameter in wood: 89 mm

• Maximum drilling diameter in steel: 13 mm

• Chuck clamping width: 1.5 - 13 mm

• Weight without battery pack: 1.7 kg

• Torque adjustment: 23 stages

Included in the package

• 1× Belt clip

• 1× Handle

• 1× Bit holder

• 1× TK-L 136 (414085)

• 1× TKE DD/PD 2G 18.0-EC HD (531280)

User Manual

Parts Diagram
