Features

• Brushless motor with higher efficiency and longer lifespan

• Electronic Management System (EMS) protects the machine, extends its lifespan, and enhances efficiency

• Impact mode for driving both short and long screws. Over-tightening or breaking of screws is prevented

• Quick-change bit holder

• Compact body makes it ideal for screwdriving in tight spaces

• Extremely high speed and torque enable efficient operation

• Speed Command: three different speed settings for various applications, including preventing overtightening of small screws

• 1/4" hex tool holder

• Electronic quick brake

• Durable gearbox housing made from die-cast aluminum with protective cover

• Ergonomically designed, slip-resistant, soft rubber grip

• Integrated LED light and battery capacity indicator

• FLEX battery system: compatible with all FLEX 18 V battery packs.

Technical Specifications

• Battery voltage: 18 V

• Battery capacity: 2.5 / 5.0 / 8.0 Ah (depending on the set)

• Torque settings: 3 levels

• Maximum torque, setting 1: 58 Nm

• Maximum torque, setting 2: 104 Nm

• Maximum torque, setting 3: 237 Nm

• No-load speed: 0 - 3700 rpm

• No-load impacts: 0 - 4200 ipm

• Dimensions (W x L x H): 119 x 76 x 208 mm

• Weight without battery pack: 1.2 kg

Content of the Set

• 1× Bit holder

• 1× Belt clip

• 1× CA 10.8/18.0 (417882)

• 1× TK-L 136 (414085)

• 1× Case

• 2× AP 18/5.0 (532733)

User Manual

Spare Parts Drawing
