Features

• Electronic Management System (EMS) protects the machine, extends its lifespan, and increases efficiency.

• Brushless motor with higher efficiency and longer lifespan.

• Anti-kickback, automatically turns off the motor in case of jamming to prevent wrist twisting.

• Turbo mode for faster and more powerful drilling, up to 27% higher rotation speed.

• Maximum torque of 158 Nm for screwing, drilling, and impact drilling, even in extreme applications. The selected torque setting remains activated when switching from drilling mode to impact drilling mode.

• Accelerator trigger with locking switch.

• Electronic quick brake.

• Durable gearbox housing made from die-cast aluminum.

• Metal quick-release chuck with thrust ring and automatic locking function.

• Right/left rotation with safety lock.

• Extendable handle offers user protection even at maximum torque.

• Ergonomic design, non-slip, soft rubber handle.

• Integrated LED light.

• LED battery capacity indicator.

• FLEX battery system: compatible with all FLEX 18 V battery packs.

Technical Specifications

• Battery voltage: 18 V

• Battery capacity: 2.5 / 5.0 / 8.0 Ah (depending on the set)

• Maximum torque, hard: 158 Nm

• Max. torque, soft: 70 Nm

• Torque adjustment: 23 steps

• Idle speed, 1st gear: 0 - 700 rpm

• Idle speed, 2nd gear: 0 - 2500 rpm

• Idle runs, 2nd gear: 0 - 40000 rpm

• Clamping width of workpiece: 1.5 - 13 mm

• Maximum drilling diameter in wood: 89 mm

• Maximum drilling diameter in steel: 13 mm

• Dimensions WxLxH: 164 x 69 x 208 mm

• Weight without battery: 1.7 kg

Included in the set

• 1× Belt clip

• 1× Handle

• 1× Bit holder
