Features

• Higher efficiency and longer life brushless motor

• Electronic management system (EMS) protects the machine, extends its life and increases efficiency.

• Right/left rotation with safety catch

• Electronic quick brake

• Acceleration switch with locking feature

• Ergonomic design with non-slip, soft rubber grip

• Integrated LED light with sustained operation function

• Ergonomically designed soft grip with on/off button and lock for continuous use

• LED battery capacity indicator

• Tool-free removable depth limiter

• Screw socket can be removed without tools

• Ergonomic two-hand operation

• Includes belt clip and bit holder

• FLEX battery system: compatible with all FLEX 18 V battery packs

Technical Specifications

• Battery voltage 18 V

• Battery capacity 2.5 / 5.0 / 8.0 Ah (depending on the set)

• Maximum torque 28 Nm

• Idle speed 0 - 4500 rpm

• Tool holder, drywall screwdriver 1/4“ internal

• Maximum screw diameter 4.2 mm

• Dimensions LxWxH 337 x 75 x 203 mm

• Weight without battery pack 0.975 kg

Contents of the Kit

• 1× UH-M 50 E6,3-C6,3 (395919)

  1× Bit holder DD/PD/ID 18.0 (430862)

  1× TK-L 136 (414085)

  1× TKE DW 45 18.0-EC (466840)

  1× Belt clip

  1× Depth stopper
